What We Produce and Why Choose SAYNOS?

Asphalt-resin-paraffin blockages (ARPD) are a significant challenge causing tangible losses in oil production globally. At SAYNOS International our mission is to revolutionize oil production worldwide by introducing cutting-edge solutions to this common problem facing by the industry.

Our flagship equipment, AWDS, is designed for automatic cleaning oil well columns cleaning. It is a cost-effective, user- and eco–friendly way to keep tubing clean.

Entrust pipe cleaning to our AWDS unit and increase production efficiency.

Automated efficiency and Safety at the core
Safety of people and the environment is our prerogative, so the AWDS control station housing is explosion-proof for safe placement at the wellhead.

In addition, the AWDS is designed for mechanical tubing cleaning with a specialized scraper (pig), eliminating the use of hazardous cleaning agents.
Versatility
and Remote control
Designed for both onshore and offshore wells, the AWDS requires minimal maintenance. Can be operated remotely and consumes minimal power.
The AWDS unit is available in a marine version
- It fits perfectly into the concept of an "unmanned" platform;
- The frequency of well cleaning is completely independent of weather conditions;
- No components to clutter deck space.
Cost-Effectiveness
The unit provides economic efficiency by minimizing the cost of well cleaning operations from wax and other deposits, thereby increasing the overall economic efficiency of the oil production process.
AWDS' Video Presentation
Constructional features
The winch is mounted on the top side of the lubricator
The induction coil (sensor) on a heated lubricator determines the location of the scraper (its top position)
The sheave with slickline is attached to the rack
The scraper isconnected with slickline
According to the specified scheme, the scrapper is lowered inside the tubing, cleaning ARPD from its inner surface
Constructional features
The winch is mounted on the top side of the lubricator
The induction coil (sensor) on a heated lubricator determines the location of the scraper (its top position)
The sheave with slickline is attached to the rack
The scraper isconnected with slickline
According to the specified scheme, the scrapper is lowered inside the tubing, cleaning ARPD from its inner surface
AWDS' features and benefits
  • User-Friendly Operation
    Thanks to its low weight (150 kg), the unit provides a simple and efficient installation process. The AWDS can be commissioned and maintained by the operator without the need for special lengthy training.
    * The only thing required is the presence of the supplier's specialist on first use.
  • Environmental Considerations
    The AWDS eliminates the need for expensive chemicals that are hazardous to the environment and reduces dependence on chemical suppliers.
  • Operational Efficiency
    - Oil production is not interrupted during periodic stripping cycles;
    - The AWDS is suitable for wells with various oil production methods including free-flow, deep-well pump, gas-lift;
    - The maximum power consumption does not exceed 0.75 kW, which contributes to energy savings;
    - The unit adapts to tubing of any diameter;
    - There is a wide range of scrapers (pigs) adapted to different downhole conditions, ensuring optimum performance;
    - The AWDS works effectively in extreme climatic conditions, from +60°C to -60°C.
  • Remote Monitoring and Control
    - The AWDS is capable of operating partially autonomously from a wind-solar system or a compact, low-power diesel generator and responding to changes in well flow to improve operational reliability;
    - It maintains constant communication with personnel via modem, allowing remote monitoring of well conditions and facilitating comprehensive well surveys using instruments attached to parts of the mechanism;
    - The station's control panel can be adapted to any language, making it easy for different teams to use.
  • Longevity and Safety
    - Designed for a long service life of 10 years or more, it requires only simple maintenance;
    - The explosion-proof design ensures safety in dangerous environments.
The AWDS has a modular design. It includes a heated lubricator with an induction coil (sensor), a gearbox, a sheave with slickline, a base for attaching a rack to the lubricator, a rack with a terminal box and a slickline tension control device (sensor), a stuffing box (SUSH), a casing and a mechanism control station.
Telemetry
Innovative system for convenient monitoring and control
  • Real-time monitoring of winch operation
    Provides live updates on the operational status.
    1
  • Consolidated overview on a single page
    Display key metrics such as mode, depth, power, speed and connection quality for all connected units.
    2
  • Access detailed performance graphs
    Analyzes operational data for any selected time period.
    3
  • Control through a Telegram bot
    Operate and manage the system conveniently using an interactive interface.
    4
  • Remote winch management
    Functions such as lifting and securing the scraper in the lubricator, starting cleaning cycles and troubleshooting can be controlled remotely until service crews arrive.
    5
  • Accessible from any internet-connected device
    Manage and monitor AWDS from computers, tablets, or smartphones without additional software installation.
    6
  • Adjust system settings remotely
    Update configurations as needed from any location.
    7
  • Customizable features
    Integrate unique functionalities such as operator presence monitoring, SMS alerts for cabinet openings, sensor data collection, and more.
    8
6
5
4
3
2
1
7
8
Provides live updates on the operational status.
Display key metrics such as mode, depth, power, speed and connection quality for all connected units.
Analyzes operational data for any selected time period.
Real-time monitoring of winch operation
Consolidated overview on a single page
Access detailed performance graphs
Telemetry
Innovative system for convenient monitoring and control
Operate and manage the system conveniently using an interactive interface.
Functions such as lifting and securing the scraper in the lubricator, starting cleaning cycles and troubleshooting can be controlled remotely until service crews arrive.
Update configurations as needed from any location.
Integrate unique functionalities such as operator presence monitoring, SMS alerts for cabinet openings, sensor data collection, and more.
Manage and monitor AWDS from computers, tablets, or smartphones without additional software installation.
Control through a Telegram bot
Remote winch management
Adjust system settings remotely
Customizable features
Accessible from any internet-connected device
When you choose Saynos, you are trusting professionals - our team will consult you, analyze your needs and provide you with a customized proposal. Our units can be purchased or leased. We provide full support for the operation, installation and further maintenance of AWDS, and you enjoy the results!
Global Reach & Commitment

We are proud to be trusted partners in markets!

  • UAE

  • Serbia

  • Vietnam

  • Central Asia: Turkmenistan, Kazakhstan, Azerbaijan

  • Africa:

    Gabon, Egypt, Libya and South Sudan

  • We are preparing tests of installations in

    Oman

    and

    Saudi Arabia

Global Reach & Commitment
We are proud to be
trusted partners in markets!
UAE
Serbia
Vietnam
Central Asia: Turkmenistan, Kazakhstan, Azerbaijan
We are preparing tests of installations
in Oman and Saudi Arabia
Africa:
Gabon, Egypt, Libya and South Sudan
About Us
We work hard to increase the efficiency of your business
  • 10 +
    Years in the oil industry
  • 100 +
    We offer over 100 different types of scrapers and provide the ability to customise one to your individual measures
  • 5 000 +
    Successfully installed AWDS
Years in the oil industry
We offer over 100 different types of scrapers and provide the ability to customise one to your individual measures
Successfully installed AWDS
10 +
100 +
5 000 +
About Us
We work hard to increase the efficiency of your business
Feedback on our equipment
Our customers confirm the quality of our products
Feedback on our equipment
